Frequency Response

40-25kHz

Recommended Amplifier Power

20-300 watts
per channel

Nominal Impedance

4 ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

Vertical Dispersion

80° x 80°

Sensitivity

92 dB @ 2.83 V/m

High Frequency Driver

1" x 1.4" (2.6cm x 3.6cm) Folded Motion™ Tweeter
with 5.25" x 1.75" (13.3cm x 4.4cm) diaphragm.

Crossover Frequency

300 Hz & 3.0 kHz

Low Frequency Driver

Two 6.5" (16.5cm) paper cones with cast aluminum baskets.

Cabinet

Ported with dipole mid-range

Low Frequency Driver Properties

Non-resonant asymmetrical chamber format.

Midrange Driver

5.25" (13.3cm) dipole paper cone with cast aluminum baskets.

Crossover Components

Custom air core coil and low DCR steel laminate inductors. Polyester film capacitors in series and low DF electrolytic capacitors in parallel. Overall system thermal/current protection.

Binding Post Inputs

Push style with banana jacks

Weight

36 lbs. (16.3 kg)

Dimensions

42.8" x 7" x 14.1"
(108.7cm x 17.8cm x 35.8cm)
